All Size PVC Waterproof PVC Electrical Insulation Tape
What are the features of our Waterproof Customized 3M Electrical Insulation Tape?
strong adhesion
good insulation
strong high temperature stability performance
not easy corrosion
High weather resistance
Soft and pliable
Strong fight corrupt capabiliy
Easy to operate
Easily tear off by hand
High pressure resistance
Color:more than seven colors available (black, white, red, yellow ,blue, green,etc)
What are the Specifications of our Waterproof Customized 3M Electrical Insulation Tape?
| Electrical Insulating Tape | UL Flame Retardant Electric Insulating Tape | ||||
| Thickness (mm) | 0.13 | 0.15 | 0.18 | 0.13 | 0.18 |
| Adhesion to Steel(N/25mm) | ≥2 | ≥2 | ≥2 | ≥2.5 | ≥2.5 |
| Tensile Strength(N/mm) | (MD)≥18; (TD)≥12 | (MD)≥20; (TD)≥14 | (MD)≥28; (TD)≥20 | (MD)≥18; (TD)≥12 | (MD)≥28; (TD)≥18 |
| Initial Tack(#) | / | / | / | ≥12# | ≥10# |
| Elongation(%) | ≥180% | ≥180% | ≥200% | ≥180% | ≥180% |
| Holding Power(min) | ≥60 | ≥60 | ≥60 | ≥60 | ≥60 |
| Temperature Resistance(℃) | 0℃~ 80℃ | 0℃~ 80℃ | 0℃~ 80℃ | 0℃~ 80℃ | 0℃~ 80℃ |
| Flame Retardation | / | / | / | One grade | One grade |
| Dielectric Strength(KV/min) | ≥5KV/min | ≥6KV/min | ≥7KV/min | ≥5KV/min | ≥7KV/min |
|
PVC Insulation Electrical Tape are made of soft pvc film(SPVC) as the backing material which are coated with rubber PSAS.They are resistant to high voltage and weather,commonly designed for connecting separated electrical wires for insulating purposes.The tapes with various colors have good adhesion,The property of insulation is excellent.Suitable for smooth or rough surface , electrical wire , cable and isolation bing-up ; was certified UL and SGS.
What are the Applications of our Waterproof Customized 3M Electrical Insulation Tape?
1. Auto Electricians – to seal and waterproof connections
2. Industrial and Household Electricians – For insulation, termination, sealing, splicing and cable repair
3. Marine and Boat use – For protecting fittings against salt corrosion and rope chaffing
4. TV Ariel and Satellite Dish Fitters – Outdoor sealing of fittings
5. Caravanning Use – For emergency repairs of hoses and pipes
6. Motorcycle use – To protect and seal against salted roads in the winter
7. Outdoor Lighting – weatherproofing connections
8. Motorsport Use – to protect vital components against water ingress and dampness
9. Gardeners – As a wrap around to hold and support plants and repairing of leaking hoses
10. Home and DIY – Endless uses
11. Underwater use
Performance Advantages:
PVC as stuff, strong stickiness;
Divide different Region;
Warning for danger, printed word available;
Easy to recognize;
Excellent anti-corrosion, anti-abrasion and anti-cold performance.
